Primary Crusher

Primary Crusher

Application fields: metallurgy, chemical, building materials, electricity, transportation and other departments.

  • Max.Feeding size: 125-1200mm
  • Output size:10-350mm

40 years of senior mining machinery solutions”

Email us ( info@hxjq.com ) , we will reply to you within 24 hours. Get a quote
China

Made in China

Two weeks delivery, custom cycle, please consult

Product Introduction

The primary crusher plays a very important role as the first step in the stone crushing line. The primary crusher has the characteristics of high crushing ratio, uniform product strength, simple mechanism, and reliable operation. It is widely used in metal and non-metal, cement, construction, sand, metallurgy and other industries.

The primary crusher can process 200 kinds of mineral ores in the primary and coarse crushing process, such as granite, basalt, limestone, rock, concrete, aggregate, gravel, dolomite and quartz. The Hot-sale models are PE400×600, PE600×900, PE900×1200, PE1200×1500 and the capacity of 16-64t/h, 50-160t/h, 220-380t/h, 400-800t/h. The maximum output can reach 1000 t/h.

Primary Crusher Features:

  1. It adopts world-level manufacturing technology and high-end manufacturing materials.

  2. More advanced movable jaw assembly makes it more durable. The movable jaw assembly uses high-quality steel casting and drives through two large-sized cast steel flywheels. In addition, the heavy eccentric shaft also adopts the forging stock which makes JC series jaw crusher extraordinarily reliable.

  3. The bearing pedestal adopts a unitary cast steel structure. The unitary cast steel bearing pedestal can ensure comprehensive fitting with the crusher rack, and at the same time, greatly increasing the radial strength of the bearing pedestal, whereas split type bearing pedestal does not have these advantages.

Product
presentation

Learn More About Us

Hongxing is engaged in the R&D and Manufacturing of mining equipment, including the crushing and screening equipment, and the industrial powder grinding equipment, etc. Products are exported to Eastern Europe, the Middle East, Africa, South Asia, Southeast Asia, and other countries.

With the “people-oriented, customer first, innovation” concept in management and service, except for offering clients our products, we also provide them with reasonable model selection, process allocation, and technical support, to make clients obtain the biggest benefit with a small investment. Thus, we are ready to do clients a favor at any time.

Technical data

  • PE/PEX Jaw Crusher
Model
Feed opening
(mm)
Max.feeding size
(mm)
Adjusting range of discharge opening
(mm)
Processing capacity
(t/h)
Rotation speed of eccentric shaft
(r/min)
Motor power
(kw)
Total weight
(t)
Dimensions
(L×W×H)
(mm)
PE-150×250 150×250 125 10-40 1-3 250 4P   5.5 0.8 720×660×850
PE-200×300 200×300 180 15-50 2-6 260 4P   7.5 1.2 910×750×990
PE-200×350 200×350 180 18-70 3-10 260 4P   11 1.5 1000×870×990
PE-250×400 250×400 210 20-60 5-21 300 6P   15 2.8 1300×1090×1270
PE-400×600 400×600 340 40-100 16-64 275 6P   30 7 1730×1730×1630
PE-500×750 500×750 425 50-100 40-110 275 6P   55 12 1980×2080×1870
PE-600×750 600×750 500 150-200 80-240 275 6P   55 15.8 2070×2000×1920
PE-600×900 600×900 500 65-160 50-160 250 6P   55 17 2190×2206×2300
PE-750×1060 750×1060 630 80-140 110-320 250 8P   110 29 2660×2430×2800
PE-800×1060 800×1060 640 130-190 130-330 250 8P   110 29.8 2710×2430×2800
PE-830×1060 830×1060 650 160-220 150-336 250 8P   110 30.7 2740×2430×2800
PE-870×1060 870×1060 660 200-260 190-336 250 8P   110 31.5 2810×2430×2800
PE-900×1060 900×1060 685 230-290 230-390 250 8P   110 33 2870×2420×2940
PE-900×1200 900×1200 750 95-165 220-380 200 8P   110 52 3380×2870×3330
PE-1000×1200 1000×1200 850 195-265 315-500 200 8P   110 55 3480×2876×3330
PE-1200×1500 1200×1500 1020 150-350 400-800 180 6P   160-220 100.9 4200×3300×3500
PE-1500×1800 1500×1800 1200 220-350 500-1000 180 8P   280-355 139 5160×3660×4248
PEX-150×750 150×750 120 18-48 8-25 320 4P   15 3.8 1200×1530×1060
PEX-250×750 250×750 210 25-60 13-35 330 6P   22 5.5 1380×1750×1540
PEX-250×1000 250×1000 210 25-60 16-52 330 6P   30 7 1560×1950×1390
PEX-250×1200 250×1200 210 25-60 20-61 330 6P   37 9.7 2140×1660×1500
PEX-300×1300 300×1300 250 20-90 16-105 300 6P   55 15.6 2720×1950×1600
  • PE/PEX Jaw Crusher
Model Max.feeding
size (mm)
Processing
 capacity
(t/h)
PE-150×250 125 1-3
PE-200×300 180 2-6
PE-200×350 180 3-10
PE-250×400 210 5-21
PE-400×600 340 16-64
PE-500×750 425 40-110
PE-600×750 500 80-240
PE-600×900 500 50-160
PE-750×1060 630 110-320
PE-800×1060 640 130-330
PE-830×1060 650 150-336
PE-870×1060 660 190-336
PE-900×1060 685 230-390
PE-900×1200 750 220-380
PE-1000×1200 850 315-500
PE-1200×1500 1020 400-800
PE-1500×1800 1200 500-1000
PEX-150×750 120 8-25
PEX-250×750 210 13-35
PEX-250×1000 210 16-52
PEX-250×1200 210 20-61
PEX-300×1300 250 16-105



For customization, please contact us.

SOLUTION

Stone Crusher In Mexico

Stone Crusher In Mexico

China Henan Hongxing Machinery Mining Machinery Co., Ltd. is a large-scale joint-stock enterprise mainly engaged in the production of heavy mining machines, as well as scientific research, production and sales. The crushing series machines produced by the company are widely used in metallurgical, ch

MORE +
Stone Crushing Plant

Stone Crushing Plant

The Stone Crushing Plant produced by Hongxing Mining Machinery has many varieties, models, fast delivery, guaranteed quality. To provide you with one-on-one after-sales service, welcome online consultation.

MORE +
Applied materials:

pebbles, granite, basalt, limestone, quartzite, construction waste, iron ore, gold ore, copper ore, etc.
