Home > Products center > Mobile Crushing > Mobile Vibrating Screen
Mobile Vibrating Screen

Mobile Vibrating Screen

Application fields: mining, stone mining, highway (railway) construction, urban construction waste treatment, etc.

  • Processing capacity: 70-580 t/ h
  • Finished size: 65-200 mm

Applied materials: limestone, granite, basalt, quartz, rock, coal, iron ore, gold ore, marble, construction waste, etc.

Mobile Vibrating Screen Introduction

This machine is used to separate materials into various sizes for further processing. The material is separated by passing it through a vibrating screen box which has a number of different sized screens, or meshes, which the material falls through like a sieve, the material falls onto attached conveyors which stock pile the end products. The end products can then be used in the building and construction industries.

Mobile vibrating screen can be used to cement, limestone, granite, basalt, aggregate, calcite, quartz, concrete, dolomite, bluestone, iron ore, coal gangue, construction waste, ferrosilicon. It is widely used in mining, quarry, road (railway) and bridge construction, urban construction waste disposal and other fields.

Mobile Vibrating Screen Features

1. The mobile vibrating screen can be used for the coarse crushing and fine crushing screening system. It can be operated independently by a single unit, or it can be flexibly composed of the system configuration unit.

2. Providing high performance screening box

3. Automatic screening movement and adjustment, screening efficiency is greater.

4. Screen layers varies from 2 to 4

5. Has the advantages of low noise, low emissions.

Product Advantages

1. The mobile vibrating screen moves the crusher and screening equipment at the front end of the process of the beneficiation equipment to the mining site, changing the traditional mining and beneficiation process.

2. The mobile vibrating screen has been selected and integrated for nearly 40 years. It not only improves the working conditions of the concentrator, but also reduces transportation costs by at least 30%.

3. Strong exciting force can endure heavy duty mining ores.

4. Reliable structure manufacturer from BV certified Supplier.

Mobile Vibrating Screen Price

Different mobile vibrating screens have different price positioning. In addition, different manufacturers, equipment configuration and model will also affect the price of equipment, so the price can't be unified. The specific price is based on the actual needs of users. To get the Hongxing mobile vibrating screen offer, you can contact the online customer service staff at any time, or send us an email: info@hxjq.com

Technical data

Model HX3S1848 HX3S1860 HX3S2160
Transportation Length(mm) 10280 11480 11480
Transportation Width(mm) 2830 2830 3150
Transportation Height(mm) 4350 4350 4350
Maximum Length(mm) 11100 11800 11800
Maximum Width(mm) 3600 3600 3970
Maximum Height(mm) 6000 6000 6500
Weight(t) 16 18 19
Tire Configuration biax fitted biax fitted biax fitted
Vibrating Screen 3YZS1848 3YZS1860 3YZS2160

Quick Way To Get Price

Tell us your need such as capacity, materials, input and output size,we send the quote to you asap

Complete the form or email us (info@hxjq.com) , we will reply to you within 24 hours.
