Rock Crusher

Rock Crusher

Application fields: metallurgy, chemical, building materials, electricity, transportation and other departments.

  • Processing capacity:1-1000t/h
  • Finished size: 0-350mm

processing materials: barite, calcite, coal, concrete, aggregate, gravel, basalt, cement, gypsum, limestone, granite, rock and so on.

Rock Crusher Introduction

The rock crusher can be used to crush once, twice and finely crushed more than 200 kinds of rough stones such as granite, basalt, limestone, rock, concrete, aggregate, gravel, dolomite and quartz. It is widely used in mining, quarry, construction, road and other industries.

The rock crushers are sold to more than 160 countries and regions around the world. Such as South Africa, Zimbabwe, Nigeria, Ethiopia, Saudi Arabia, the Philippines, Indonesia, Mexico, Brazil and other countries

Features of Rock Crusher

As the indispensable first step of the stone product line, the rock crusher machine always plays an important role. The product features are:

1). Big crushing ratio.

2). Simple structure, convenient installation and maintenance and lower operation cost.

3). The percentage of water can reach to the level of 8% after material being crushed.

4). Cubic product shape, lower flakiness content.

5). Accumulation density, low iron pollution.

Our advantage

The company covers an area of 350,000 square meters. It has a heavy industry factory of 260,000 square meters. It is a large-scale joint-stock enterprise integrating scientific research, production and sales. Nearly 40 years of mining equipment technology and experience make the granite crusher simple and reasonable in structure, large in crushing ratio and high in output. Strict quality management guarantees the superior quality of each machine.

We provide you with one-stop worry-free service from pre-sales to mid-sales to after-sales, and integrate value-added services into any aspect that is closely related to each customer.

Get a Quote

In order to let customers know more about our products, we have more detailed product information and price list. If you want a quote for the product, you can get a quote by clicking on the online customer on the right, or send an email to info@hxjq.com. You can also write your contact information and project information in the message box at the bottom of the page, such as product name, capacity, materials, etc. We will contact you!

Technical data

icon
Model
Feed opening
(mm)
Max.feeding size
(mm)
Adjusting range of discharge opening
(mm)
Processing capacity
(t/h)
Rotation speed of eccentric shaft
(r/min)
Motor power
(kw)
Total weight
(t)
Dimensions
(L×W×H)
(mm)
PE-150×250 150×250 125 10-40 1-3 250 4P   5.5 0.8 720×660×850
PE-200×300 200×300 180 15-50 2-6 260 4P   7.5 1.2 910×750×990
PE-200×350 200×350 180 18-70 3-10 260 4P   11 1.5 1000×870×990
PE-250×400 250×400 210 20-60 5-21 300 6P   15 2.8 1300×1090×1270
PE-400×600 400×600 340 40-100 16-60 275 6P   30 7 1730×1730×1630
PE-500×750 500×750 425 50-100 40-110 275 6P   55 12 1980×2080×1870
PE-600×750 600×750 500 150-200 80-240 275 6P   55 15.8 2070×2000×1920
PE-600×900 600×900 500 65-160 50-160 250 6P   55 17 2190×2206×2300
PE-750×1060 750×1060 630 80-140 110-320 250 8P   110 29 2660×2430×2800
PE-800×1060 800×1060 640 130-190 130-330 250 8P   110 29.8 2710×2430×2800
PE-830×1060 830×1060 650 160-220 150-336 250 8P   110 30.7 2740×2430×2800
PE-870×1060 870×1060 660 200-260 190-336 250 8P   110 31.5 2810×2430×2800
PE-900×1060 900×1060 685 230-290 230-390 250 8P   110 33 2870×2420×2940
PE-900×1200 900×1200 750 95-165 220-380 200 8P   110 52 3380×2870×3330
PE-1000×1200 1000×1200 850 195-265 315-500 200 8P   110 55 3480×2876×3330
PE-1200×1500 1200×1500 1020 150-350 400-800 180 6P   160-220 100.9 4200×3300×3500
PE-1500×1800 1500×1800 1200 220-350 500-1000 180 8P   280-355 139 5160×3660×4248
PEX-150×750 150×750 120 18-48 8-25 320 4P   15 3.8 1200×1530×1060
PEX-250×750 250×750 210 25-60 13-35 330 6P   22 5.5 1380×1750×1540
PEX-250×1000 250×1000 210 25-60 16-52 330 6P   30 7 1560×1950×1390
PEX-250×1200 250×1200 210 25-60 20-61 330 6P   37 9.7 2140×1660×1500
PEX-300×1300 300×1300 250 20-90 16-105 300 6P   55 15.6 2720×1950×1600
