Toothed Roller Crusher

Toothed Roller Crusher

Application fields: coal, metallurgy, mine, chemistry and building materials industry especially in large coal mines and coal dressing plants.

  • Feeding size: ≤1150mm
  • Output:30-300t/h

40 years of senior mining machinery solutions”

Email us ( info@hxjq.com ) , we will reply to you within 24 hours. Get a quote
China

Made in China

Two weeks delivery, custom cycle, please consult

Product Introduction

The toothed roll crusher has a small volume, large crushing ratio, low noise, simple structure, and high productivity. and products are sold to more than 120 countries and regions around the world. Such as South Africa, Zimbabwe, Zambia, Algeria, Australia, Malaysia, Nepal, Ethiopia, Saudi Arabia, the Philippines, Mexico, Brazil, and other countries

Nearly 40 years of mining equipment technology and experience make the toothed roller crusher a simple, rational and compact structure. Rigorous quality management guarantees the superior quality of each machine.

Toothed Roller Crusher Features:

  1. Compared with other types of crushers, this series of crusher has many advantages such as big crushing ratio, low noise, low vibration, low energy consumption, small coverage size, simple and convenient maintenance.;

  2. This machine adopts mechanical, equipment and hydraulic protective device and interlocking device, thus effectively protecting the electromotor, crusher, and the whole system.

  3. This product becomes the first choice of the heat-engine plant to replace import crushing equipment due to its advantages of high efficiency, energy conservancy, and environment protection.

Product
presentation

Toothed Roll Crusher & Roll Crusher

Compared with the roller crusher, the toothed roller crusher has a larger capacity of 30-300t/h, and a larger feeding size of 200-1150 mm, discharging size 15-200mm.

The toothed roll crusher has become the first choice of the heat-engine plant to replace import crushing equipment.

Technical data

  • Toothed Roller Crusher
Model Roller
diameter
(mm)
Roller
length
(mm)
Max.
Feeding
 Size
(mm)
Discharging
size(mm)
Output
(t/h)
Motor
power
(kw)
Total
weight(t)
Overall
dimension
(L×W×H)
(mm)
2PGC600×500 600 500 200-450 15-100 30-60 4P   11×2 3.8 2450×1800×950
2PGC600×800 600 750 300-600 20-120 60-100 4P   18.5×2 7.2 4500×1900×1350
2PGC800×1000 800 1000 500-800 30-150 100-160 4P   22×2 12.6 2550×2050×1100
2PGC1000×1000 1000 1000 700-950 30-200 150-200 6P   45×2 18.8 2780×4100×1550
2PGC1200×1200 1200 1200 800-1050 30-200 180-250 6P   55×2 29.5 2780×3200×1980
2PGC1500×1200 1500 1200 1000-1150 30-200 200-300 6P   75×2 38.6 8010×4500×2050
  • Toothed Roller Crusher
Model Max.Feeding
 Size(mm)
Discharging
size(mm)
2PGC600×500 200-450 15-100
2PGC600×800 300-600 20-120
2PGC800×1000 500-800 30-150
2PGC1000×1000 700-950 30-200
2PGC1200×1200 800-1050 30-200
2PGC1500×1200 1000-1150 30-200

For customization, please contact us.

Processing materials:

river pebble, granite, basalt, coal, iron ore, limestone, quartz, diabase, iron ore, gold, copper, etc.
